Implementing a combined ECU and TCU tune from TVS Engineering transforms vehicle performance by harmonising engine output with transmission dynamics. Known for its precision in DSG technology and engine tuning, TVS ensures that adjustments to the engine control unit and transmission control unit enhance each other, creating a seamless interaction between shifting patterns and power delivery.

This integrated tuning approach not only sharpens throttle response and gear transitions but also optimises overall vehicle dynamics, making each drive more engaging and responsive. PERON Automotive, as the UK distributor, provides expert guidance to customers and a robust dealer network, ensuring access to these superior TVS Engineering solutions that significantly elevate vehicle performance and driving pleasure.

EA288 (Diesel) Performance Figures

2.0 TDI CR 204hp: 250 hp / 530 Nm

2.0 TDI CR 198hp: 250 hp / 530 Nm

2.0 TDI CR 150hp: 200 hp / 435 Nm

2.0 TDI CR 114hp: 180 hp / 370 Nm
2.0 TDI CR 110hp: 180 hp / 370 Nm
2.0 TDI CR 102hp: 180 hp / 370 Nm
2.0 TDI CR 90hp: 180 hp / 370 Nm

EA888.2 (Petrol) Performance Figures

2.0 TSI 204hp: 290 hp / 450 Nm

2.0 TSI 150hp: 290 hp / 450 Nm

STAGE 1 ECU Calibration (TVS Stage 2)

TVS ECU Stage 2 software is the first real step into increasing performance! Hereby maximum performance out of a stock engine setup will be achieved within all safety limits. Performance numbers are based on RON 98 fuel, but is available for different fuel grades as well.

100% Stock Engine
Data analysing and fine-tuning

OPTIONAL FEATURES

Temperature Protection
Improved Fuel Efficiency
Vehicle Speed Limiter adjustment
Exhaust Gas Recirculation (EGR) adjustment
Diesel Particulate Filter (DPF) adjustment
Start/Stop OFF

Stage 2+ DSG Calibration

TVS DSG Stage 2+ software is the best priced all-in-one package for your DSG transmission! It does include all drivability & life extender features, necessary performance modifications for tuned vehicles and additional options as well!

Mild and strong tuned vehicles
Improved drivability
Extended gearbox lifetime
Increased gearbox performance

IMPROVED DRIVABILITY: Unique shifting strategies matching the engine for ultra smooth up- and downshifting

Optimized D Shift Program
Optimized S Shift Program
Optimized M Shift Program
Optimized Cruise Control Program

LIFE EXTENDER OPTIONS: Sustainable software solutions for extended gearbox lifetime

1st Gear de- or reactivation (optional)
Improved clutch cooling
Improved thermomanagment

PERFORMANCE OPTIONS: Various necessary software modifications for fastest performance during acceleration and up- and downshifting while keeping drivability smooth. Perfectly matching shifting strategies for any engine and gearbox combination.

Maximum gearbox torque increased to 699 Nm
Increased maximum clutch pressure to 14-15 bar
Necessary torque limiters raised
Improved up- and downshifting speed (D+S+M mode)
Enhanced shifting paddle response
Improved take-off control (D+S+M mode)
Improved torque reduction during shifting (D+S+M mode)
Customised upshift RPM setpoints
Customised downshift RPM setpoints
Optional automatic upshift and downshift deactivation
Kick-down deactivation (optional)

LAUNCH CONTROL: Launch control activation and/or enhancement included user definable launch settings

Improved LC response time for quicker launches
Multi-step LC RPM limits
Different LC modes for D/S/M mode
LC with ESP ON activation

ADDITIONAL OPTIONS: Other optional features available for certain models

Gear Display Indicator (MFA) activation
Reduced engine braking
Coasting disabling
